Offer Cutter Cerrig Segment Diemwnt
Disgrifiad:
Manyleb:
| Segmentau ar gyfer llafn llifio diemwnt 300-800mm | ||||||
| Diamedr | Trwch Craidd (mm) | Dimensiwn Segment (mm) | Nifer y Dannedd | |||
| mm | modfedd | Hyd | Trwch | Uchder | ||
| 300 | 12" | 2.0/2.2 | 40 | 2.8/3.0 | 8/10/12/15 | 21 |
| 350 | 14" | 2.2/2.4 | 40 | 3.0/3.2 | 8/10/12/15 | 24 |
| 400 | 16" | 2.6/2.8 | 40 | 3.4/3.6 | 8/10/12/15 | 28 |
| 450 | 18" | 2.8/3.0 | 40 | 4.0/4.2 | 8/10/12/15 | 32 |
| 500 | 20" | 2.8/3.0 | 40 | 4.0/4.2 | 8/10/12/15 | 36 |
| 600 | 24" | 3.6 | 40 | 4.6 | 8/10/12 | 42 |
| 700 | 28" | 4 | 40 | 5.2 | 8/10/12 | 42 |
| 800 | 32" | 4.5 | 40 | 6.0 | 8/10/12 | 46/57 |
| Segmentau ar gyfer 900-3500mm llafn sengl/aml | ||||||
| Diamedr | Trwch Craidd (mm) | Dimensiwn Segment (mm) | Nifer y Dannedd | |||
| mm | modfedd | Hyd | Trwch | Uchder | ||
| 900 | 36" | 5 | 22/24 | 6.0/6.6 | 12/13/15 | 64 |
| 1000 | 40" | 5.5 | 22/24 | 6.4/7.0 | 12/13/15 | 70 |
| 1200 | 48" | 6 | 22/24 | 7.4/8.0 | 12/13/15 | 80 |
| 1400 | 55" | 6.5 | 22/24 | 7.8/8.4 | 12/13/15 | 92 |
| 1600 | 64" | 7.2 | 22/24 | 8.4/9.0 | 12/13/15 | 108 |
| 1800 | 72" | 8 | 22/24 | 9.2/9.8 | 12/13/15/20 | 120 |
| 2000 | 80" | 8 | 22/24 | 9.5/10.5 | 12/13/15/20 | 128 |
| 2200 | 88" | 9 | 22/24 | 10.5/11.5 | 12/13/15/20 | 132 |
| 2500 | 110" | 9 | 22/24 | 11.5/12.5 | 12/13/15/20 | 140 |
| 3000 | 120" | 10 | 22/24 | 12.5/13.5 | 12/13/15/20 | 160 |
| 3500 | 140" | 10 | 22/24 | 13.5/14.5 | 12/13/15/20 | 180 |
* Mae manylebau eraill ar gael ar gais.
FAQ
C1: Ydych chi'n ffatri neu'n gwmni masnachu?
A1: Rydym yn ffatri.
C2: Sut alla i wybod yr ansawdd?
A2: Ceisiwch wneud treial, ar ôl i chi ddefnyddio ein segmentau, yna byddwch chi'n gwybod yr ansawdd. Yn ôl eich gofynion, cynhyrchu cynhyrchion yr hyn yr ydych ei eisiau. Nid yw Pls yn poeni, mae gennym 16 mlynedd o brofiad mewn diwydiant offer diemwnt.
C3: Beth am yr isafswm maint?
A3: Mae unrhyw orchymyn maint ar gael.
C4: Sut alla i gael y segmentau diemwnt addas gorau?
A4: Rhowch fwy o fanylion i ni am eich carreg a'ch llafn llifio diemwnt. Gallwn roi cyngor i chi.
C5: Beth yw eich telerau talu?
A5: Dylai'r taliad fod yn 100% T / T cyn ei anfon.
C6: Beth allwn ni ei wneud os byddwn yn canfod na all eich cynhyrchion redeg yn dda?
A6: Rhowch y manylion data i ni. Gallwn ddadansoddi'r rhesymau posibl, ceisio dod o hyd i'r broblem, yna dweud wrthych sut i'w datrys.
Manyleb:
*250-800mm
| Diamedr(mm) | Maint Segment(mm) | Segment RHIF.(pcs/set) | Dull Weldio | Strwythur | ||
| Hyd | Lled | Uchder | ||||
| 250 | 40 | 2.5 | 8/10 | 18 |
Weldio Arian neu Weldio Laser |
Aml-Haen neu Dim-Haen
|
| 300 | 40 | 3.2 | 8/10 | 21 | ||
| 350 | 40 | 3.2/3.4 | 8/10 | 24/25 | ||
| 400 | 40 | 3.6 | 8/10 | 28 | ||
| 450 | 40 | 4.0 | 8/10 | 32 | ||
| 500 | 40 | 4.2 | 8/10 | 36 | ||
| 550 | 40 | 4.4 | 8/10 | 38 | ||
| 600 | 40 | 4.6 | 8/10 | 42 | ||
| 700 | 40 | 5.0 | 8/10 | 50 | ||
| 725 | 40 | 5.5 | 8/10 | 50 | ||
| 800 | 40 | 5.2 | 8/10 | 46 | ||
*900-3500mm
| Diamedr(mm) | Dimensiwn Segment(mm) | Segment No. | Dull Weldio | Strwythur | ||
| Hyd | Lled | Uchder | ||||
| 900 | 24 | 7.0/6.5 | 10/12/15/20 | 64 |
Weldio Arian neu Weldio Laser |
Aml-Haen neu Dim-Haen |
| 1000 | 24 | 7.0/6.5 | 10/12/15/20 | 70 | ||
| 1100 | 24 | 7.4/6.8 | 12/15/20 | 74 | ||
| 1200 | 24 | 7.5/7.0 | 12/15/20 | 80 | ||
| 1300 | 24 | 8.0/7.5 | 12/15/20 | 88 | ||
| 1350 | 24 | 8.4/7.7 | 12/15/20 | 88 | ||
| 1400 | 24 | 8.5/8.0 | 12/15/20 | 96 | ||
| 1600 | 24 | 9.0/8.7/8.4 | 12/15/20 | 108 | ||
| 1700 | 24 | 9.4/8.9/8.4 | 12/15/20 | 112 | ||
| 1800 | 24 | 9.5/9.0 | 12/15/20 | 120 | ||
| 2000 | 24 | 10.5/9.5 | 12/15/20 | 128 | ||
| 2200 | 24 | 11.5/10.5 | 12/15/20 | 132/136 | ||
| 2500 | 24 | 12/11.5/11 | 15/20/25/30 | 140 | ||
| 2700 | 24 | 12/11.5/11 | 15/20/25/30 | 140 | ||
| 3000 | 24 | 12.5/12/11.5 | 15/20/25/30 | 160 | ||
| 3500 | 24 | 13/12.5/12 | 15/20/25/30 | 180 | ||
